Rosco Maximizer 3B Asphalt Distributor 10-137
Illustrated Parts List (IPL)
Washdown System Parts List
Item
No. Part Number Qty. Description Remarks
23223 1 Washdown System
3 32881 1 •Hose,04X300,04fpx-04Re,350
4 33163 2 •Clamp,Hose,.50-.91,Worm,#08
6 33328 1 •Fitt,90 08Mp-08Hb,Crimped
-7 33596 4 •Tie Wrap,.188X7.5
9 33602 2 •Conn,Butt,16-14 Ga
10 985043 1 •Pump,Water/Fuel,Diaphragm,12V
-1001 984385 1 ••Port Kit,08 Threaded
19 36206 1 •Decal,Washdown Pump Buzzer
20 36208 1 •Buzzer,12 Vdc,Continuous Tone
21 36926 1 •Strainer,Lqd,100Mesh,Nyl,08Fp
23 986227 1 •Reel,W/Hose,Spraydown
Attaching Parts
-2301 80164 4 ••Washer,Lock,.500
-2302 80186 2 ••Cshh,.500-13X1.75 Gr5
-2303 80354 2 ••Nut,Flexloc,.500-13,Full,Lt
-2304 920200 1 ••Reel,W/Hose,Spray Down
-2305 920220 1 ••Nozzle,Fuel Washdown,W/Handle
-23051 901210A 1 •••Nozzle,Fuel,Washdown (Nozzle Only)
-23052 984948 1 •••Handle,Fuel,Washdown (Handle Only)
-2306 986226 1 ••Mount Assy,Hose Reel
24 6298 1 •Fitt,Str 04Mp-09Mpf,Lh Lp Gas
25 6352 5 •Hose,08,Push-On,250
26 986274 1 •Holster Assy,Nozzle,Washdown
Attaching Parts
-2601 80963 1 ••Washer,Flat,Sae,.312
-2602 986272 1 ••Holster Tube,Washdown System
-2603 986273 1 ••Tab,Washdown Holster
30 80141 4 •Washer,Flat,Uss,.313
31 80207 2 •CSHH,.312-18X.75,Gr5
32 80351 2 •Nut,Flexloc,.312-18,Full,Lt
35 80924 4 •Nut,Flexloc,#10-24,Full,Lt
36 80995 8 •Washer,Type A Plain,#10
37 80997 4 •Mach Scr,Ph,#10-24X2.00
38 99503 1 •Pipe,45,04Fp,Mi
39 99512 1 •Pipe,90,08Fp,Mi
40 99526 1 •Pipe,90,08Mp-08Fp,Mi
41 99569 1 •Pipe,Tee,08Fp,Mi
