Rosco Maximizer 3B Asphalt Distributor
5-3
Component Location
Table 5-1. Outside Overview
ITEM NO. CONTROL NAME FUNCTION
1 Hydraulic Pump Mounted on the front of truck. It is a variable displacement pump that
provides power to the hydraulic motor that turns the asphalt pump.
2 Tank Capacity Indicator Located on the front and the rear of the tank. Measures the quantity of
material in the tank.
3 Asphalt Tank An insulated tank for holding the hot bituminous asphalt material
Ladder Provides access to top of tank and opening
4 Top Opening Located at top of tank. Provides an opening for î›™lling the tank. Has a
dipstick for measuring tank quantity, a loading screen, overow pipe, and
tank vent.
5 Hydraulic Tank Mounted on the left or right side of truck. Supplies hydraulic uid to the
hydrostatic system.
6 GPS Speed Sensor Monitors the speed and distance traveled by the distributor and reports the
information to the Plus One Controller in-cab. Mounted on truck cab roof.
7 Diesel Fuel Tank Mounted on the left or right side of tank. Diesel fuel is used for the diesel
burners (when equipped). Tank may contain diesel fuel or solvent for
internal clean-out and external cleaning.
8 Thermometers Located on the front, lower left side of the tank. Indicates the temperature
of material in the tank. Pencil thermometer and dial thermometers are
standard, with in-cab monitor of tank temperature displayed on Plus One
Controller.
