Rosco Maximizer 3B Asphalt Distributor
5-9
Component Location
ITEM NO. CONTROL NAME FUNCTION
7 Left Spraybar Extend /
Retract
This switch is a momentary switch which allows the operator to extend
(switch left) and retract (switch right) the left spraybar assembly in 4 inch
increments for the precise alignment of asphalt spray. The left spray bar
assembly moves in the direction of the switch as the operator holds it in
place. Once released the switch springs to the center position and spraybar
movement stops at the nearest 4 inch increment.
8 Right Spraybar Extend /
Retract
This switch is a momentary switch which allows the operator to extend
(switch right) and retract (switch left) the right spraybar assembly in 4
inch increments for the precise alignment of asphalt spray. The spray bar
assembly moves in the direction of the switch as the operator holds it in
place. Once released the switch springs to the center position and spraybar
movement stops at the nearest 4 inch increment.
9 Left 4 ft. Spray Nozzle
Activation Switch
This switch corresponds to the 4 ft. section on the center left of the
spraybar. Placing the switch in the down position activates the 12 spray
valves for this 4 ft. section of spraybar. As the spraybar is extended, a
mechanical î›™nger engages the actuator of each valve to the open position.
Placing the Spraybar Master Switch (Figure 5-2,4) in the SPRAY position
then allows asphalt to spray from the activated nozzles.
10 Right 4 ft. Spray Nozzle
Activation Switch
This switch corresponds to the 4 ft. section on the center right of the
spraybar. Placing the switch in the down position activates the 12 spray
valves for this 4 ft. section of spraybar. As the spraybar is extended, a
mechanical î›™nger engages the actuator of each valve to the open position.
Placing the Spraybar Master Switch (Figure 5-2,4) in the SPRAY position
then allows asphalt to spray from the activated nozzles.
11 Spraybar Raise / Lower
Switch
This switch is a momentary switch which hydraulically moves the spraybar
up (switch up) and down (switch down) to adjust spray height. Movement
continues as long as the switch is held in position or until the limits of travel
are reached. Once released the switch springs to the center position and
spraybar movement stops.
12 Soft Keys The color display on the In-Cab Controller is surrounded by 8 buttons
labeled 1 thru 8. These buttons are soft keys meaning they function
according to the labels next to them on the color display. The screen will
indicate the function of each button depending on the screen displayed at
the time.
13 ESC Button Use this button to cancel a function or escape from a screen.
14 OK Button Use this button to accept a change or to acknowledge a selection on the
color display.
15 Navigation Buttons (Left
/ Right)
These buttons are used to navigate the curser in the color display. Pressing
the LEFT button moves the curser or selection to the left. Pressing the
RIGHT button moves the curser of selection to the right.
16 Navigation Buttons (Up
/ Down)
These buttons are used to navigate the curser in the color display. Pressing
the UP button moves the curser or selection up. Pressing the DOWN button
moves the curser or selection down.
Table 5-2. Main In-Cab Control Panel (continued)
