Rosco Maximizer 3B User Manual

5
Rosco Maximizer 3B Asphalt Distributor
5-15
Component Location
Table 5-5. LPG Burner System
ITEM NO. CONTROL NAME FUNCTION
1 To Tank Valve (Not
Shown)
Controls the ow of the fuel from the tank. Turn counterclockwise to open
and clockwise to close. Activated by burner control switch on the in-cab
controller (Figure 5-2,2).
2 Regulator The regulator is used to set the pressure. Turn clockwise (CW) to increase
and set the pressure. Turn counterclockwise (CCW) to reduce the pressure.
Always set the pressure at 10 to 20 PSI for operation.
3 Shut-Off Valve Controls the ow of fuel to the burner. Turn counterclockwise to open the
valve to provide gas to the burner. Turn clockwise to close the valve and
extinguish the burner.
4 Pilot Light Valve (on
manual ignition only)
Controls the operation of the burner pilot light. Turn clockwise to close the
valve when lighting the pilot light. Turn counterclockwise to allow full ow
after the burners are ignited.
5 Solenoid: (Not Shown) Shuts off fuel to burners when high temperature is reached
