Rosemount 3051 - Page 18

January 2017
18
Quick Start Guide
4. Some variants of the equipment have reduced markings on the nameplate. Refer to
the Certificate for full equipment marking.
I1 ATEX Intrinsic Safety and Dust
Certificate: BAS97ATEX1089X; Baseefa11ATEX0275X
Standards: EN60079-0:2012, EN60079-11:2012, EN60079-31:2009
Markings: HART: II 1 G Ex ia IIC T5/T4 Ga, T5(–60 °C ≤ T
a
≤ +40 °C),
T4(–60 °C ≤ T
a
≤ +70 °C)
Fieldbus/PROFIBUS: II 1 G Ex ia IIC Ga T4(–60 °C ≤ T
a
≤ +60 °C)
DUST: II 1 D Ex ta IIIC T95 °C T
500
105 °C Da (–20 °C ≤ T
a
≤ +85 °C)
Special Conditions for Safe Use (X):
1. The apparatus is not capable of withstanding the 500 V insulation test required by
clause 6.3.12 of EN60079-11:2012. This must be taken into account when installing
the apparatus.
2. The enclosure may be made of aluminum alloy and given a protective polyurethane
paint finish; however care should be taken to protect it from impact or abrasion if
located in Zone 0.
3. Some variants of the equipment have reduced markings on the nameplate. Refer to
the Certificate for full equipment marking.
IA ATEX FISCO
Certificate: BAS97ATEX1089X
Standards: EN60079-0:2012, EN60079-11:2009
Markings: II 1 G Ex ia IIC T4 Ga (–60 °C ≤ T
a
≤ +60 °C)
Special Conditions for Safe Use (X):
1. The apparatus is not capable of withstanding the 500 V insulation test required by
clause 6.3.12 of EN60079-11:2012. This must be taken into account when installing
the apparatus.
2. The enclosure may be made of aluminum alloy and given a protective polyurethane
paint finish; however care should be taken to protect it from impact or abrasion if
located in Zone 0.
Table 7. Input Parameters
Parameter HART Fieldbus/PROFIBUS
Voltage U
i
30 V 30 V
Current I
i
200 mA 300 mA
Power P
i
0.9 W 1.3 W
Capacitance C
i
0.012 μF 0 μF
Inductance L
i
0 mH 0 mH
Table 8. Input Parameters
Parameter FISCO
Voltage U
i
17.5 V
Current I
i
380 mA
Power P
i
5.32 W
Capacitance C
i
<5 nF
Inductance L
i
<10 μH
