Rosemount 3051 - Page 20

January 2017
20
Quick Start Guide
Special Conditions for Safe Use (X):
1. If the apparatus is fitted with optional 90 V transient suppressor, it is not capable of
withstanding the 500 V insulation test required by IEC60079-11. This must be taken
into account when installing the apparatus.
2. The enclosure may be made of aluminum alloy and given a protective polyurethane
paint finish; however, care should be taken to protect it from impact or abrasion if
located in Zone 0.
IECEx Mining (Special A0259)
Certificate: IECEx TSA 14.0001X
Standards: IEC60079-0:2011, IEC60079-11:2011
Markings: Ex ia I Ma (–60 °C ≤ T
a
≤ +70 °C)
Special Conditions for Safe Use (X):
1. If the apparatus is fitted with optional 90 V transient suppressor, it is not capable of
withstanding the 500 V insulation test required by IEC60079-11. This must be taken
into account when installing the apparatus.
2. It is a condition of safe use that the above input parameters shall be taken into account
during installation.
3. It is a condition of manufacture that only the apparatus fitted with housing, covers and
sensor module housing made out of stainless steel are used in Group I applications.
N7 IECEx Type n
Certificate: IECEx BAS 09.0077X
Standards: IEC60079-0:2011, IEC60079-15:2010
Markings: Ex nA IIC T5 Gc (–40 °C ≤ T
a
≤ +70 °C)
Special Condition for Safe Use (X):
1. The apparatus is not capable of withstanding the 500 V insulation test required by
IEC60079-15. This must be taken into account when installing the apparatus.
Table 10. Input Parameters
Parameter HART Fieldbus/PROFIBUS
Voltage U
i
30 V 30 V
Current I
i
200 mA 300 mA
Power P
i
0.9 W 1.3 W
Capacitance C
i
0.012 μF 0 μF
Inductance L
i
0 mH 0 mH
Table 11. Input Parameters
Parameter HART Fieldbus/PROFIBUS FISCO
Voltage U
i
30 V 30 V 17.5 V
Current I
i
200 mA 300 mA 380 mA
Power P
i
0.9 W 1.3 W 5.32 W
Capacitance C
i
0.012 μF 0 μF <5 nF
Inductance L
i
0 mH 0 mH <10 μH
