6. End user is not permitted to change any components inside, but to settle the problem in
conjunction with manufacturer to avoid damage to the product.
7. When installation, use and maintenance of this product, observe following standards:
GB3836.13-2013 “Electrical apparatus for explosive gas atmospheres Part 13: Repair
and overhaul for apparatus used in explosive gas atmospheres”
GB3836.15-2000 “Electrical apparatus for explosive gas atmospheres Part 15: Electrical
installations in hazardous area (other than mines)”
GB3836.16-2006 “Electrical apparatus for explosive gas atmospheres Part 16:
Inspection and maintenance of electrical installation (other than mines)”
GB3836.18-2010 “Explosive Atmospheres Part 18: Intrinsically Safe System
GB50257-2014 “Code for construction and acceptance of electric device for explosion
atmospheres and fire hazard electrical equipment installation engineering”
EAC – Belarus, Kazakhstan, Russia
IM Technical Regulations Customs Union (EAC) Intrinsic Safety
Certificate: RU C-US.GB05.B.00289
Markings: 0Ex ia IIC T4, T5 Ga X
See Table 2 at the end of the Product Certifications section for entity parameters.
Japan
I4 TIIS Intrinsic Safety
Certificate: TC19154
Markings: Ex ia IIC T4, T4(–20 °C ≤ T
a
≤ +60 °C)
See Table 2 at the end of the Product Certifications section for entity parameters.
5.6 Additional Certifications
SBVBureau Veritas (BV) Type Approval
Certificate: 26325/A2 BV
Requirements: Bureau Veritas Rules for the Classification of Steel Ships
Table 2. Entity Parameters (Sensor Terminals)
Parameter FM CSA
ATEX, IECEx, NEPSI,
EAC, TIIS, INMETRO
Voltage U
o
(V) 6.51 6.6 6.6
Current I
o
(mA) 3.12 3.2 3.2
Power P
o
(mW) 5.1 20.4 5.3
Capacitance C
o
(μF) 22 22 22
Inductance L
o
(H) 1 1 1
