Table 2. (continued)
Flange Bolt Torque and Bolt Load Specifications for 8705 (EN 1092-1)
Size Code Line Size
Polyurethane, Linatex, Adiprene and Neoprene Liners
PN 10 PN 16 PN 25 PN 40
(Newton-meter) (Newton-meter) (Newton-meter) (Newton-meter)
010 1 inch (25 mm) 20
015 1.5 inch (40 mm) 30
020 2 inch (50 mm) 40
025 2.5 inch (65 mm) 35
030 3 inch (80 mm) 30
040 4 inch (100 mm) 40 50
050 5.0 inch (125 mm) 50 70
060 6 inch (150mm) 60 90
080 8 inch (200 mm) 90 60 90 110
100 10 inch (250 mm) 70 80 130 170
120 12 inch (300 mm) 80 110 130 180
140 14 inch (350 mm) 110 150 210 280
160 16 inch (400 mm) 150 190 280 410
180 18 inch (450 mm) 130 230 220 280
200 20 inch (500 mm) 150 260 300 350
240 24 inch (600 mm) 200 380 390 560
