European Certifications
E1 ATEX Flameproof
Certificate No: KEMA 07ATEX0073 X
II 2G Ex de IIC T6 or
IIC 2G Ex de [ia] IIC T6
without LOI (-50 °C  Ta  +60 °C)
with LOI (-20 °C  Ta  +60 °C)
V
max
= 250 V AC or 42 V DC
0575
ED ATEX Flameproof
Certificate No: KEMA 07ATEX0073 X
II 2G Ex de IIB T6 or
II 2G Ex de [ia] IIB T6
without LOI (-50 °C  Ta  +60 °C)
with LOI (-20 °C  Ta  +60 °C)
V
max
= 250 V AC or 42 V DC
0575
ND ATEX Dust
Certificate No: KEMA 07ATEX0073 X
II 1D Ex tD A20 IP66 T100 °C or
with I.S. outputs
II G [Ex ia] IIC
without LOI (-50 °C  Ta  +60 °C)
with LOI (-20 °C  Ta  +60 °C)
V
max
= 250 V AC or 42 V DC
IP 66
0575
Special Conditions for Safe Use (KEMA 07ATEX0073 X):
Contact Rosemount Inc. for information on the dimensions of the flameproof joints. The
property class of the security screws which attach the flowtube or junction box to the
transmitter is SST A2-70.
Installation Instructions:
The cable and conduit entry devices and blanking elements shall be of a certified
flameproof or increased safety type, suitable for the conditions of use and correctly
installed. With the use of conduit, a certified stopping box shall be provided immediately
to the entrance of the enclosure.
