Keypad Programming Instructions (AY-Q6350)
16 AY-Q6x50 Family Installation and Programming Manual
Table 2 shows the names of all the programming menus. Default
factory settings are marked by an asterisk (*).
Table 2: Programming Menu
Menu Description Default
1 Selecting Keypad Transmission Format
1 – Single Key, Wiegand 6-Bit (Rosslare Format, Default)
2 – Single Key, Wiegand 6-Bit with Nibble + Parity Bits
3 – Single Key, Wiegand 8-Bit, Nibbles Complemented
4 – 4 Keys Binary + Facility Code, Wiegand 26-Bit
5 – 1 to 5 Keys + Facility Code, Wiegand 26-Bit
6 – 6 Keys BCD and Parity Bits, Wiegand 26-Bit
7 – Single Key, 3x4 Matrix Keypad
8 – 1 to 8 Keys BCD, Clock & Data Single Key
*
2
Selecting
MIFARE Card Transmission Format
1 – Wiegand 26-Bit (default)
2 – Clock & Data
3 – Wiegand Card + PIN
4 – Wiegand 26-Bit with Facility Code Output
5 – Wiegand 32-Bit
6 – Wiegand 32-Bit Reverse Output
7 – Wiegand 34-Bit
8 – Wiegand 40-Bit
*
3 Changing the Programming Code
1234
4 Changing the Facility Code
001
6 Backlight Options
Off
On (Default)
Off until key press when on for 10 seconds
Dimmed until key press when on for 10 seconds
*
0 Return to Factory Default Settings
