Re a d e r Func tio na lity
AYC-Fx4 a nd AYC-G x4 fa mily ma nua l Pa g e 22
The MD-P64 inte rfa c e unit o utp uts the d a ta re c e ive d to 7 o utp uts
e m ula ting a ke yb o a rd . The inte rfa c e unit will no t a ffe c t a ny d a ta
tha t it re c e ive s fro m the p ro ximity re a d e r whe the r it is 26-Bit
Wie g a nd o r Clo c k & Da ta .
Ke y p re sse d = ASC II Va lue
0 = '0' ( 0x30 he x )
6 = '6' ( 0x36 he x )
1 = '1' ( 0x31 he x )
7 = '7' ( 0x37 he x )
2 = '2' ( 0x32 he x ) 8 = '8' ( 0x38 he x )
3 = '3' ( 0x33 he x )
9 = '9' ( 0x39 he x )
4 = '4' ( 0x34 he x )
*= '* ' ( 0x2A he x )
5 = '5' ( 0x35 he x )
# = '# ' ( 0x23 he x )
Option 8: 1 to 8 Keys BCD, Clock & Data
Buffe rs up to 8 ke ys a nd o utp uts ke yp a d d a ta witho ut a fa c ility
c o d e like sta nd a rd C lo c k a nd Da ta c a rd o utp ut.
The ke yp a d PIN c o d e c a n b e o ne to e ig ht dig its lo ng . The PIN
c o d e le ng th is se le c te d while p ro g ra mming the re a d e r fo r O p tio n
8. The re a d e r will tra nsm it the d a ta whe n it re c e ive s the la st ke y
p re ss o f the PIN c o d e . The d a ta is se nt a c ro ss the two d a ta o utp ut
line s a s b ina ry d a ta in C lo c k & Da ta fo rm a t.
If the "*" ke y o r the "# " ke y a re p re sse d d uring PIN c o d e e ntry, the
ke yp a d will c le a r the PIN c o d e e ntry b uffe r, g e ne ra te a b e e p a nd
is re a d y to re c e ive a ne w ke yp a d PIN c o d e .
If the e ntry o f the d ig it ke yp a d PIN c o d e is d isrup te d a nd no
numb e r ke y o r "# " ke y is p re sse d within 5 se c o nd s, the ke yp a d will
c le a r the PIN c o d e e ntry b uffe r, g e ne ra te a me d ium le ng th b e e p
a nd is re a d y to re c e ive a ne w ke yp a d PIN c o d e .
No te :
• Whe n using the ke yp a d tra nsmissio n fo rm a t "1 to 8 ke ys
BC D, C lo c k & Da ta " (O p tio n 8) a n a d d itio na l inp ut is
re q uire d to spe c ify the num b e r o f ke ys in the PIN c o d e .
