C o ntro lle r Func tio na lity
AYC-Fx4 a nd AYC-G x4 fa mily ma nua l Pa g e 52
If the a ssig nm e nt c o d e is va lid ,
the Mo d e ind ic a to r will sto p
fla shing .
The c o ntro lle r is no w w a iting fo r a no the r slo t num b e r. De p re ss the
# ke y to m o ve to the ne xt slo t o r e nte r a ne w slo t numb e r. If yo u
d o no t wish to c o ntinue , d e p re ss the # ke y twic e a nd the
c o ntro lle r will re turn to its no rm a l m o d e .
6.9.17. Relay Code Assignment using Search Method
1) Ente r the p ro g ra mming
m o d e .
2) De p re ss 9 to e nte r Me nu 9.
• The Mo d e LED will turn g re e n.
• The Do o r LED will turn
o ra ng e .
3) Ente r 000 fo r use r slo t a c c e ss.
• The Do o r LED will fla sh
o ra ng e .
The c o ntro lle r is no w wa iting fo r the p rima ry c o d e o f the use r.
4) Ente r the p rima ry c o d e
b e lo ng ing to the use r.
• The Mo d e LED will fla sh
g re e n.
5) Ente r the a ssig nme nt dig it fo r the c urre nt use r slo t:
• 1 will a c tiva te the Lo c k Strike re la y o nly d e a fult
• 2 will a c tiva te the Auxilia ry re la y o nly
• 3 will a c tiva te the Lo c k Strike a nd Auxilia ry re la ys.
If the a ssig nm e nt d ig it is va lid, thre e b e e p s will b e he a rd a nd the
c o ntro lle r will re turn to its no rm a l m o d e .
If the a ssig nm e nt d ig it is inva lid , a lo ng b e e p will so und a nd the
c o ntro lle r will wa it fo r a no the r a ssig nme nt dig it to b e e nte re d .
