Controller Functionality
AYC-Qx4 family manual Page 46
Auxiliary Mode 4
Auxiliary input function: Toggles normal/secure modes
Auxiliary output activated by: direct shunt (explanation below)
E.g. In auxiliary mode 4, the controller is capable of bypassing an
alarm zone by shunting an alarm system’s door sensor. The
auxiliary output is to be wired in parallel to the door sensor output.
When in use, the auxiliary output is normally open and the door
sensor functions normally. When a valid code is entered, the
auxiliary relay shunts the door sensor for the duration of the shunt
time, as defined by the auxiliary setting. If the door is left open
longer than the shunt time, an alarm will be triggered.
Auxiliary Mode 5
Auxiliary input function: Door Monitor
Auxiliary output activated by: Shunt (explanation below)
E.g. In auxiliary mode 5, the controller is capable of shunting an
alarm system. In this mode, the auxiliary input is to be wired to the
magnetic contact switch on the door. The auxiliary relay is wired
to the alarm system. Without a valid code entered, the auxiliary
relay will match the condition of the magnetic contact switch; if
the door opens, the auxiliary relay will open; if the door closes, the
auxiliary relay will close. When a valid code is entered, a count
down for maximum shunt time, as defined by the auxiliary setting,
begins; if the door is not closed before the maximum shunt time,
the alarm will be triggered.
