Controller Functionality
AYC-Qx4 family manual Page 47
Auxiliary Mode 6
Auxiliary input function: Door Monitor
Auxiliary output activated by: Forced entry
E.g. In auxiliary mode 6, the controller can trigger the auxiliary
relay if the door has been forced. If the Siren Settings is enabled
the siren will be activated.
In this mode, the auxiliary input functions as a door monitor switch
and is wired to the magnetic contact switch on the door. The
auxiliary relay is to be wired to the alarm system. If the door is
forced open, the controller will wait for the period of the forced
door delay time to elapse and then, it will activate the auxiliary
relay. The auxiliary setting sets the forced door delay period.
Auxiliary Mode 7
Auxiliary input function: Door Monitor
Auxiliary output activated by: Door Ajar (door held open)
E.g. In auxiliary mode 7, the controller can trigger the auxiliary
relay, if it detects that the door has been held open (ajar) too
long. In this mode the auxiliary input functions as a door monitor
switch and is wired to the magnetic contact switch on the door.
The auxiliary relay is to be wired to the alarm system. If the door is
opened, the controller will wait for the door ajar delay time to
elapse and if the door does not close prior to the end of this
period, the controller will activate the auxiliary relay. The auxiliary
setting defines the door-ajar time.
