Rotex A1 BG - Page 34

34
FA ROTEX A1 BGe - 02/2014
7 x Gas burner
A1 BG-Type A1 BG 25(F)*-e
G1G 126
Blower type
Gas type
(Test gas)**
Setting for
control
measurement
Power setting CO
2
-content in %
(±0.2%)
O
2
-content
in %
(
± 0.1%)
Speed Load in kW
in % in rpm
Natural gas
E/H
(G20)
Full load
100 5700 27.5 9.8 3.5
93 5300 25.4 9.7 3.6
Basic load
23 1310 5.6 9.3 4.4
23 1310 5.6 9.3 4.4
Natural gas
LL/L
(G25)
Full load
98 5570 26.7 9.6 3.5
93 5300 25.2 9.5 3.6
Basic load
23 1310 5.7 9.1 4.4
23 1310 5.7 9.1 4.4
Propane*
(G31)
Full load
100 5400 26.9 11.5 3.5
89 4800 23.8 11.4 3.5
Basic load
35 1890 9.7 11.0 4.2
24 1300 6.1 10.9 4.4
Butane*
(G30)
Full load
89 4800 26.7 11.7 3.5
89 4800 26.7 11.7 3.5
Basic load
35 1890 9.9 11.2 4.2
24 1300 6.5 11.1 4.4
* Liquid petroleum gas version (F) ** Compare with the information on the yellow sticker attached to the burner ROTEX-Factory settings
Tab. 7-2 Flue gas set values and speed limits for A1 BG 25(F)-e for different types of gas
A1 BG-Type A1 BG 40(F)*-e
G1G 126
Blower type
Gas type
(Test gas)**
Setting for
control
measurement
Power setting CO
2
-content in %
(±0.2%)
O
2
-content
in %
(± 0.1%)
Speed Load in kW
in % in rpm
Natural gas
E/H
(G20)
Full load
100 6000 40.7 9.8 3.5
85 5100 34.3 9.7 3.7
Basic load
30 1800 10.8 9.3 4.3
25 1500 8.6 9.3 4.4
Natural gas
LL/L
(G25)
Full load
100 6000 41.6 9.6 3.5
85 5100 34.7 9.5 3.7
Basic load
30 1800 9.3 9.1 4.3
28 1680 8.3 9.1 4.4
Propane*
(G31)
Full load
100 6000 42.0 11.5 3.5
80 4800 33.4 11.3 3.7
Basic load
30 1800 11.8 10.9 4.3
25 1500 9.6 10.9 4.4
Butane*
(G30)
Full load
95 5700 41.9 11.7 3.5
80 4800 34.9 11.6 3.7
Basic load
30 1800 11.7 11.2 4.3
25 1500 9.4 11.1 4.4
* Liquid petroleum gas version (F) ** Compare with the information on the yellow sticker attached to the burner ROTEX-Factory settings
Tab. 7-3 Flue gas set values and speed limits for A1 BG 40(F)-e for different types of gas
