Rotex A1 BG - Setting Ignition and Ionisation Electrodes

7 x Gas burner
FA ROTEX A1 BGe - 02/2014
39
7.3.7 Setting ignition and Ionisation electrodes
The electrodes are factory-set to the optimum value.
For adjusting: see fig. 7-10.
CAUTION!
Ignition electrodes can break with cold deformation.
Ɣ Dismantle the burner before adjusting the
electrodes and make the electrodes glow by using
a solder lamp.
Fig. 7-10 Adjustment of the ignition and ionisation electrodes
