FA ROTEX A1 BGe - 02/2014
12 x Technical data
12.2 Heating circulation pump and 3-way diverter valve (A1 - all types)
12.3 Gas type, connection pressures
Parameter Unit Heating circulation pump
Type Grundfos UPM2 15-70 CES87
Voltage V ~230
Frequency (power supply) Hz 50
Maximum power consumption W 70
Protection type IP 44
Permitted overpressure bar 3
Maximum pumping height m 7.0
Energy efficiency EEI < 0.23
3-way diverter valve (accessory)
Type Honeywell VC4012 (SPST)
Voltage V ~230
Frequency (power supply) Hz 50
Maximum power consumption W 4.3
Protection type IP X0B
Turnaround time S 6
Tab. 12-2 Technical details of the integrated heating circulation pump and the 3-way diverter valve from connecting kit VSA1
Gas type Rated pressure in mbar Min. inlet pressure in mbar Max. inlet pressure in mbar
Natural gas E/H 20 17 25
Natural gas LL/L 20 18 25
Liquid petroleum gas 50 42.5 57.5
Tab. 12-3 Permitted gas inlet pressure
Country of destination Appliance category Nominal connection pressure in mbar
Natural gas Liquefied petroleum
gas
Natural gas Liquefied petroleum
gas
DE I
2 ELL
I
3 B/P
20 50
AT, CH I
2 H
I
3 B/P
20 50
DK, FI, NO, SE I
2 H
I
3 B/P
20 28-30/30
GB, GR, IE, IT I
2 H
I
3+
20 28-30/37
CH, ES, PT I
2 H
I
3+
20 28-30/37
NL I
2 L
I
3 B/P
25 28-30/30
LU I
2 E
I
3 B/P
20 50
FR I
2 Esi
I
3 P
20/25 37
BE I
2 E(S)B
I
3 P
20/25 37
PL I
2 E
I
3 B/P
20 37
HU I
2 H
I
3 B/P
25 30
Tab. 12-4 Countries of destination, device categories and associated gas connection pressures
