Tab. 7-1 Short names in hydraulic drawings (1)
Name Meaning Remark Order No.
SCS 538/16/0 Solaris Sanicube INOX (1 charging heat exchanger) 16 45 16
SCS 538/16/16 Solaris Sanicube INOX (2 charging heat exchangers) 16 45 17
SCS 538/0/0 Sanicube Solaris INOX 16 45 15
SC 538/0/0 Sanicube as storage tank for external heat exchanger Accessory 16 50 15
GSU S GasSolarUnit with solar heating support
GSU 520S 15 71 10
GSU 520S F 15 71 20
GSU 530S 15 71 21
GSU 530S F 15 71 23
GSU GasSolarUnit without solar heating support
GSU 320 15 70 25
GSU 320 F 15 70 26
GSU 535 15 71 40
GSU 535 F 15 71 45
ESU 509 E-SolarUnit ESU 509 15 70 50
A1-Inline A1 BO 20i 15 48 10
A1 BO 27i 15 48 11
A1 BO 35i 15 48 12
A1 BG 25i 15 58 00
A1 BG 40i 15 58 01
1Cold water
2Hot water
3 Heating feed
4 Heating return flow
P
K
Boiler circuit pump Included in GSU/A1-Inline scope of supply.
3W-UV 3-way valve
UV1 3-way valve
UV2 3-way valve Accessory 15 60 34
t
WW
Storage tank temperature sensor Included in GSU/SCS scope of supply.
t
V
Heating feed temperature sensor Included in GSU/A1-Inline scope of supply.
t
R
Heating return flow temperature sensor Included in GSU/A1-Inline scope of supply.
t
AG
Flue gas temperature sensor Accessory 15 70 52
t
AU
Outdoor temperature sensor
SV Safety pressure relief valve
5 Mixer circuit Optional
AMK1 Mixer group Accessory 15 60 44
P
Mi
Mixer circuit pump Included in AMK1 scope of supply.
MI 3-way mixer with drive motor Included in AMK1 scope of supply.
t
Mi
Mixer circuit feed temperature sensor Accessory 15 60 62
HEM1 Heating circuit extension module Accessory 15 60 61
TSF Storage tank temperature sensor Accessory 15 60 63
6 Circulation circuit Optional
P
Z
Circulation pump on site
7 Return flap, return check valve on site
7a Gravity brake (for cold/hot water connection) Accessory 16 50 70
8 Solar circuit Optional
SK High performance flat solar panel Accessory
16 43 06
16 43 04
16 43 05
RPS3 Solaris control and pump unit Accessory 16 41 06
P
S1
Circulation pump Included in RPS3 scope of supply.
P
S2
Booster pump Included in RPS3 scope of supply.
t
S, R
Solaris return temperature sensor Included in RPS3 scope of supply.
t
S
Solaris tank temperature sensor Included in RPS3 scope of supply.
t
S, V
Solaris feed temperature sensor Included in RPS3 scope of supply.
t
K,H
Wood-fired boiler temperature sensor for SCS-TR Included in Connect AB scope of supply.
t
K
Solaris solar panel temperature sensor Included in Connect AB scope of supply.
