3 Transport and Storage
During transportation, care should be taken to ensure that
your actuator is protected from impact. In the unfortunate
event of your actuator receiving an impact, the actuator
should be inspected by a Rotork trained technician (for
transportation purposes, handwheels are supplied separately).
If your actuator cannot be installed immediately, store it in a
clean, dry ventilated location that is off the floor and protect it
from dust and dirt.
CK Range valve actuators are supplied with temporary plastic
transit cable entry plugs. These are for short term use and if
the unit is likely to be stored for a period of time, these must
be replaced with metal plugs which have been sealed with
PTFE tape.
If the actuator has to be installed but cannot be cabled, it is
recommended that the plastic transit cable entry plugs are
replaced with metal plugs which are sealed with PTFE tape
until you are ready to connect the incoming cables.
The CK plug and socket assembly will preserve internal
electrical components perfectly if left undisturbed. Rotork
cannot accept responsibility for deterioration caused on-site
once the covers are removed. Every CK Range actuator is fully
tested before leaving the factory to give years of trouble free
operation, providing it is correctly commissioned, installed and
sealed. Technical documentation that is supplied with each
unit must be kept safe for future reference.
CK Range Safe Use and Installation Manual
6
