4.1 CK Standard
Electric Actuator Nameplate
The actuator name plate will enable you to identify your unit.
Example below:
Plug and socket housing
Motor
Name Plate
Mark Description
1 Facility Address
2 Actuator Model
3 Serial Number
4 Maximum Torque
5 Minimum Torque
6 Output Speed (RPM)
7 Lubricant
8 Temperature Range
9 Manufacturing Date
10 Enclosure Rating
11 Unit Barcode (Factory Use)
12 QR Code
13 Flange Size
14 Maximum Unit Weight
15 Spare Line (Tag Information)
Hand Wheel
Conduit Entries
Switch Mechanism Cover
Protective Earth Connection
(M6x1p x 10 Deep)
Hand / Auto lever
4 Actuator Identification
Keeping the World Flowing
7
www.rotork.com
14
1
2
3
4
5
6
7
8
9
10
11
15
12
13
To Next Page
