Machine Parts 7 SG9M Manual
S. NO. PART NO. DESCRIPTION QTY/M/C
1 430-514 BASE 1
2 VGS-512 SET SCREW 5/16” NF X 3/8” 4
3 VGS-513 PLUG (BRASS) 16
4 VGS-505 BALL BEARING 6
5 VGS-503 WASHER OD 0.350”, ID 0.203” X 0.05” THK 8
6 VGS-506 ECCENTRIC PIN 2
7 430-501 PLATE 2
8 VGS-507 GRUB SCREW 10-32 X ¼” DOG PT. 2
9 VGS-508 WASHER 3/8” 8
10 430-509 HEX. BOLT 4
11 VGS-504 PIN 2
12 VGS-502 PIN 2
13 VGS-511 GRUB SCREW 10-32 X ¼” FLAT PT. 2
14 430-518 WEIGHT 1
15 430-519 ALLEN HD. SCREW (1/2” UNC X 2.5”) 2
16 430-521 SWIVALING BLOCK 1
17 ALLEN HD. SCREW 2
18 430-525 SWIVALING PIN 1
19 430-522 PIN HOLDER 1
20 GRUB SCREW ¼” BSW 1
21 430-527 WASHER 1
22 430-528 NUT 3/8” BSW 1
23 VGS-536 BUSH 4
24 VGS-544 LEVER 4
25 VGS-545 HAMMER RIVET 16
26 VGS-546 NYLOCK NUT 3/8” BSW 4
27 VGS-547 CYLINDER (LH) 1
28 VGS-538 GUIDE PIN 4
29 VGS-539 LEVER 2
30 VGS-540 PISTON 2
31 VGS-540A PIN 2
32 VGS-540B PISTON PIN 4
33 VGS-540C SPRING 4
34 VGS-540D ‘O’ RING 2
35 VGS-543 GRUB SCR. 8-32 X 20mm F. POINT 4
36 VGS-541 BRACKET 4
37 VGS-542 BUTTON HD SCR 10-32 X 1/4” 4
38 VGS-537 CYLINDER (RH) 1
39 VGS-535 NUT ( NEST) 1
40 430-534 STUD 1
41 430-520 SPACER 1
42 430-523 ADJUSTING NUT 1
43 430-524 RETAINING RING 1
44 430-526 INCLINATION ROD 1
45 430-548 RETAINING RING 2
46 430-549 SPRING PIN 1/8” X 3/4” 2
47 430-551 NEEDLE BEARING 1
48 430-550 THRUST BEARING 2
49 430-531 KNOB 1
50 430-530 GRUB SCR. ¼” BSW X ¼” FLAT PT. 1
51 430-529 SET SCREW 5/16” BSW X ¼” F.PT. 1
52 430-532 HANDLE 1
