Rottler SG9M - Page 53

Machine Parts 8 SG9M Manual
S. NO. PART NO. DESCRIPTION QTY/M/C
53 430-533 ALLEN HD SCREW 5/16” BSW X 2.50’ 1
54 NYLOCK NUT 3/8” UNF 1
55 VGS-640 NUT 1
56 430-670 EYE BOLT 1
57
NC-35
ECCENTRIC CLAMP 2
58
NC-39
LEVER PIN 1
59 VGS-522 KNOB 1
60 VGS-629 PIVOT PIN 1
61 430-510 ECCENTRIC COLLAR 2
62 430-552 TAPER PIN 2
63 430-628 RING 1
64 430-630 ALLEN HEAD SCR. ¼” BSW X ½” LONG 4
65
NC-34
CLAMP 1
66 430-516 LEVER 1
67 430-517 KNOB 1
68 430-514-S-1 CLAMP PLATE (NOT SHOWN) 1
69 430-514-A BASE COVER PLATE (NOT SHOWN) 1
70 430-514 S-2 SHIPPING CLAMP (NOT SHOWN) 2
