Machine Parts 10 SG9M Manual
S. NO. PART NO. DESCRIPTION QTY/M/C
1
NC-69
DRIVE SHAFT 1
2 430-671 RUBBER SEAL 1
3 KS-08-07 QUICK NUT 1
4 KS-08-03 SPRING 2
5 KS-08-02 PAD 2
6 430-659 TAPER ROLLER BEARING 1
7 430-608 COLUMN 1
8 430-648 BALL BEARING 1
9 430-605 SPACER 1
10
NC-32
BRASS PAD 2
11 430-623A C.PT. GRUB SCR. 3/16” X 1/2” BSW 2
12 430-623B F.PT GRUB SCR. 3/16” X 1/2” BSW 1
13
NC-33
STOP PLATE LOCK NUT 1
14 430-603A LOCK WASHER 1
15 430-603 LOCK NUT 2
16 430-601 END STOPPER 1
17 KS-08-06 COVER 1
18 KS-08-05 PIN 1
19 KS-08-04 SPRING 1
20 KS-08-01 STOP PIN 1
21 430-711 EXTENSION BLOCK LEFT 1
22 430-716 EXTENSION BLOCK RIGHT 1
23 430-614A SPINDLE HOUSING 1
23A 430-614S SHIPPING CLAMP 1
24 430-627 GRUB SCR. D.PT. 5/16” NF X 1.25” LONG 4
25 430-609 ALLEN SCREW 5/16’ NF X 1.5” LONG 5
26 430-621 GRUB. SCR. D. PT. 5/16” NF X 1/2" LONG 1
27 430-621a GRUB SCR. F. PT. 5/16” NF X 0.200” LONG 1
28 430-619 GRUB SCREW 3/8” BSW X ½” LONG 1
29 430-619A BRASS PLUG 1
30 430-615 (A & B) CONTROL STOP SCREW ASSY. 1 EACH
31 430-607 C’SINK SCR. ¼” X ½” BSW 2
32 430-620 CONTROL STOP LATCH 1
33
430-606-1
STOP ROD BLOCK 1
34 430-617 PIN 1
35 430-618 SPRING 1
36
430-664-1
FEED KNOB 1
37 430-665 SET SCR. F. PT. 5/16” NF X 3/8” LONG 1
38 C’ SINK SCR. 10-32 X ¼” LONG 1
39
430-663-I
END COVER 1
40 430-662 WASHER 1
41
430-660-I
WORM SHAFT 1
42
430-631A-I
BUSH 1
43
430-631-I
PINION 1
44 430-632 WOODRUF KEY 1
45
430-661-I
WORM WHEEL 1
46 430-667 PIN 2
47 430-634 SPACER 1
48
430-635-I
HAND WHEEL 1
49
430-635-2
HAND WHEEL EXTENSION 1
50 430-668 COVER PLATE 1
51 430-666 C’ SINK SCREW 4
