Machine Parts 11 SG9M Manual
S. NO. PART NO. DESCRIPTION QTY/M/C
52 430-636 WASHER 1
53 430-636A C’SINK SCR.1/4” X 1/2” BSW 1
54 430-639 M4-BALL PLUNGER SCREW 1
55
VGS-641-1
INDICATOR MTG. FLAT 1
56 VGS-642 INDICATOR MTG. ROD 1
57
430-643A-1
DIAL CLAMP 1
58 VGS-646 INDICATOR 1
59 430-645A KNOB 1
60 430-616 LEVELING PIN 1
61
NC-37
PLATE (LEVELING PIN) 1
62
430-650-1
SHROUD 1
63
NC-48-1
RIGHT SIDE COVER 1
64 430-647b LEFT SIDE COVER 1
65
NC-49-1
TOP COVER 1
66 430-713 BACK COVER FRAME 1
67 430-715 BACK DOOR 1
68 430-722 FIX BLOCK 2
69 430-723 SWING BLOCK 2
70 430-724 PIN 2
71
430-712-1
HOLDER 1
72 430-714-R GAS SPRING (150N) 1
73 430-717-R TUBE 1
74
430-625R-1
PLATE 1
75
430-643 B
CLAMP 1
76
430-625R-IV
STOPPER PLATE 1
77
NCL-87
SPACER 1
78
NC-40-1
FRONT COVER 1
79
555-15-25
DRIVE ADAPTOR 1
80
555-15-38
SCREW 2
81
555-15-39
LOCK NUT 1
82
NCL-73
ACTUATING ROD 1
83 BEARING 2
84
NCL-70
BEARING HOUSING 1
85
NC-93
STOPPER 1
86 SCREW 1
87
NCL-97
CABLE BRACKET 1
88
NCL-81
CYLINDER COVER 1
89 SCREW 4
