2018-06-20/1.11A
Piranha/Cobia & Quick Check Getting Started
Quick Check
36
The most common meter settings are available (depending on used detector(s).
To close the Excel connection, click "x" in the upper right corner of the Excel control window. Both the
window and the used Excel workbook will be closed. If necessary, you are asked to save.
1.10.2 Connect (Fixed format)
Data is sent to Excel using a fixed format that is compatible with the format used in Excel workbooks used
with Xi and X2 view. The format is described in detail below.
To connect to the workbook:
First go to Options in Quick Check and make sure that the checkbox "Fixed format (Excel connect)" is
checked.
1. Activate a Quick Check display.
2. Click on the Excel button.
3. A dialogue is shown, select "Connect to workbook".
