Publication date: Jan, 2009
Revision A1
2
1. Introduction
1-1. Overview of ES-2410C
ES-2410C, 8 Fast Ethernet + 2 Gigabit L2 Plus Managed Switch,
implemented 8 10/100Mbps TP + 2 Gigabit dual media ports with TP/SFP(or GBIC),
is a standard switch that meets all IEEE 802.3/u/x/z Gigabit, Fast Ethernet and
Ethernet specifications. The switch can be managed through RS-232 serial port via
directly connection, or through Ethernet port using Telnet or Web-based
management unit, associated with SNMP agent. With the SNMP agent, the network
administrator can logon the switch to monitor, configure and control each port’s
activity in a friendly way. The overall network management is enhanced and the
network efficiency is also improved to accommodate high bandwidth applications.
In addition, the switch features comprehensive and useful function such as DHCP
Option 82, QoS (Quality of Service), Spanning Tree, VLAN, Port Trunking,
Bandwidth Control, Port Security, SNMP/RMON and IGMP Snooping capability via
the intelligent software. It is suitable for both metro-LAN and office application.
•
Model Description
Model Port 9, 10 Configurations
ES-2410C Two types of media --- TP and SFP Fiber
ES-2410Q Two types of media --- TP and GBIC Fiber
10/100/1000Mbps TP is a standard Ethernet port that meets all IEEE
802.3/u/x/z Gigabit, Fast Ethernet specifications. 1000Mbps SFP Fiber transceiver
is a Gigabit Ethernet port that fully complies with all IEEE 802.3z and 1000Base-
SX/LX standards.
1000Mbps Single Fiber WDM (BiDi) transceiver is designed with an optic
Wavelength Division Multiplexing (WDM) technology that transports bi-directional
full duplex signal over a single fiber simultaneously.
For upgrading firmware, please refer to the Section 3-20 or Section 4-2-2 for
more details. The switch will not stop operating while upgrading firmware and after
that, the configuration keeps unchanged.
