1-4. View of ES-2410C
1-4-1. User Interfaces on the Front Panel (Button, LEDs and Plugs)
There are 8 TP Fast Ethernet ports and 2 slots for optional removable
modules on the front panel of the switch. LED display area, locating on the front
panel, contains a CPURUN, Power LED and 26 ports working status of the switch.
Fig. 1-1 Full View of ES-2410C with SFP/GBIC Module
Fig. 1-2 Front View of ES-2410C with SFP Module
Power Indication
Fast Ethernet LED SET Mode: ACT/FDX/SPD
Gi
g
abit Dual Media Port:
RESET Button:
RESET button is used to
reset the management
system.
