RuiDeng RD6006 User Manual

声明：本说明书著作权归杭州睿登科技有限公司所有，未经允许任何单位或个人不得用于商业用途。
32
1.1 Technical Parameter
Model
RD6006
RD6006-W
RD6012
RD6012-W
Input voltage range
6-70.00V
Output voltage range
0-60.00V
Output current range
0-6.000A
0-12.00A
Output power range
0-360W
0-720W
Input voltage measurement resolution
0.01V
Output voltage setting measurement resolution
0.01V
Output current setting measurement resolution
0.001A
0.01A
Battery voltage measurement resolution
0.01V
Input voltage measurement accuracy
±(1%+5 digits)
Output voltage accuracy between setting and
measurement
±(0.3%+3 digits)
Output current accuracy between setting and
measurement
±(0.5%+5 digits)
Battery voltage measurement accuracy
±(0.5%+3 digits)
Automatic cut off current value when charging
10mA
100mA
Output ripple typical
100mV VPP
250mV VPP@6A
Working temperature range
-10℃~40℃
External sensor Temperature detection range:
-10℃~100℃/0℉~200℉
External sensor Temperature detection accuracy:
±3℃/±6℉
Constant voltage mode response time
2ms（0.1A-5A Load）
2ms（0.1A-5A Load）
Constant voltage mode load regulation
±(0.1%+2 digits)
Constant current mode load regulation
±(0.1%+3 digits)
Capacity measurement range
0-9999.99Ah
Energy measurement range
0-9999.99Wh
Capacity and energy statistical error
±2％
Buck working mode
Voltage drop >1V and >10%
Cooling fan start condition
Output voltage>40V or
Output current>4A or
System temperature>45℃
Output current>8A or
System temperature>45℃
Cooling fan shut down condition when working
Output voltage <40V and
Output current <3.9A and
System temperature <45℃
Output current <7.9A and
System temperature <45℃
Over temperature protection
System temperature >80℃
Screen brightness setting
0-5(6 level in total)
Screen
2.4 inch color HD display
Weight(with package)
About 607g
About 642g
Product dimension
167*81*65mm
Support USB communication
yes
Support WiFi communication
No
yes
No
yes
