1.3.2 Back Panel
R: Power source input interface
S: External temperature sensor interface
U: Communication module interface
NOTE:
Power source input interface must be
connected to 6-70V constant DC power source. The
external sensor cable (as shown on right) must be
connected to the external temperature sensor
interface. The fan interface cannot be connected to
other fans. When the system temperature is higher than 80℃, the output will be
shut down and show OTP on the scrren. CR1220 is the clock battery (Please prepare
