声明：本说明书著作权归杭州睿登科技有限公司所有，未经允许任何单位或个人不得用于商业用途。
52
CU: Actual Output Voltage
DE: Output Voltage Preset value
CV: Actual Output Current
CX: System Temperature(℃)
CY: System Temperature(℉)
4.3.1 Basic Functions
PC software operation video: https://youtu.be/mjt1RMaah1Y
The basic functions of PC software: voltage/current preset, data group quick call
out, calibration fine tuning, brightness setting, voltage and current curve exporting.
You can rotate the wheel or enter the value to set the voltage and current, the graph
above the button shows the real-time voltage and current curve. You can zoom in
and out the curve by using the mouse wheel, double click the curve to auto adjusts
the axis, you can right click on the curve to clean the curve or export the curve data
to picture or excel.
4.3.2 Firmware Update
Firmware update operation video: https://youtu.be/NOoLfDw0DiY
Press and hold “ENTER” and power on RD6012, enter the boot mode, then
connect it to computer, there will be “boot mode” in the mode information text box,
then click “Firmware Update”, a firmware update prompt will pop up on the
interface, and click “Now” to upgrade. (You can update the firmware under the
normal mode, if it cannot be started up normally, you should press and hold the
“ENTER” button and power on, update it under boot mode. It doesn’t support
firmware update under WiFi connection mode).
