Connect Wi-Fi for the first time, please insert the WiFi board to the right place,
then power on RD6012, you will see the blue LED blinks. Set the communication
interface to WIFI, restart RD6012, then place the RD6012 and the mobile phone close
to the 2.4G router (the mobile phone must also be under the same 2.4G network,
and the router must disable the AP isolation function and the WMM function).
RD6012 will wait for the phone to connect as shown in Picture 3. Press “BN” to
call out the sidebar, clicks on the “Network distribution” as shown in Picture 5. There
will be “Initializing...” displayed on the screen as shown in Picture 6. After 10 seconds,
the RD6012 will obtain the IP address of the mobile phone as shown in Picture 4.
Then click “Next”, fill in the WIFI password as shown in Picture 7, click "CONFIRM"
below, wait for about 20s, it will show success as shown in Picture 8, then RD6012
will automatically restart, the distribution network is successful, return to the main
interface and click “BO”(Connection). If the distribution network fails, please power
off the module and re-operate in the same way (multiple networking failures you can
watch the video and try to use the hotspot of the mobile phone to test).
3.2.3.2 Proper Wi-Fi Connection
Android APP download and connection operation video:
https://youtu.be/QwyBEUCnp9c
When power on RD6012, it will connect Wi-Fi first, and then detect if it can be
connected to APP, and it may not be connected successfully if the phone is under
screen-lock status or the APP is running at the background. If the IP address of the
phone has changed, you need to press the “left direction” button and then press
“ENTER” button to reset the net, repeat 3.2.3.1 operation.
2.2.3.3 APP Operation
Android APP operation video: https://youtu.be/hqrF4keTfbE.
Click “BV” to set the output voltage, and use the wheel “BY” to adjust the value,
the “BZ”, “CA” to change the position of cursor, click “CB” to set the parameter. Click
“BP” to exports the voltage-current curve to excel file, up to 24 hours document can
be recorded.
NOTE:
1. There are many kinds of Android phone, so the user interfaces maybe
different on some brand phones or different scales of the same brand.
2. Application permission requirements, allow the necessary permissions when
the APP is installed (allow background running, using Bluetooth, operation on the
folder, reading the application list, etc.) and also set the permissions of the APP after
installation: Allow background running, never shut down when lock screen, allow
self-starting (it is used to prevent the system from forcibly exiting the APP when
recording data), etc.
