R&D department
2018/08/01
Time GMT date & time of coordinates
Hyperlink Hyperlink to Google maps with coordinates: latitude and longitude
Speed Current vehicle speed, km/h
Ignition Ignition status
Syntax: pass webcoords
Can be 3 different SMS message responses.
1. When GPS data is available.
Response example: 2015-05-11 13:01, https://www.google.com/maps/?q=54.7404933,25.2222366, speed: 94, ignition:
ON
2. When GPS not available.
Response example: GPS data not available. Ignition: ON
3. When GPS not available but was available then device can return last known coordinates and the time shows
when the coordinates were taken.
Response example: No GPS. Last entry: 2015-05-16 17:32, https://www.google.com/maps/?q=54.7404933,25.2222366,
speed: 65, ignition: ON, current ignition: OFF
1.1.22 setiotime – set output for temporary period
Using this feature, FM is able to switch the DOUTs for temporary period of time. User must provide pulse lengths
for logical '1' & '0' values.
SMS format example: pass setiotime 1 500 0 500,0 200 1 300
Description:
Parameter Description
pass SMS password
setiotime Command Identifier
1 DOUT1 first logical state (1/0)
500 DOUT1 first logical state length (ms)
0 DOUT1 second logical state (1/0)
500 DOUT1 second logical state length (ms)
, DOUT separator
0 DOUT2 first logical state (1/0)
200 DOUT2 first logical state length (ms)
1 DOUT2 second logical state (1/0)
300 DOUT2 second logical state length (ms)
Impulse resolution is 10 ms. Minimum impulse duration is 10 ms. If Eco-panel is connected, minimum resolution
and duration is 50 ms. When the FM device receive the setiotime it stores the status of DOUT’s and after the sequence
15
