Revision 4 - December 17,1998 Ryan TCAD 9900 Series Page 1-4
Shield Limits: Terminal Mode Standard Mode Enroute Mode Unrestricted
Mode
Model 9900B 200 to 1000 FT,
0.5 to 1.5 iNM
500 to 1500 FT
1.0 to 3.0 iNM
1000 to
2000 FT
2.0 to 6.0 iNM
10,000 FT
and 6.0 iNM
Model 9900A 200 to 1000 FT,
0.5 to 1.5 iNM
500 to 1500 FT
1.0 to 3.0 iNM
1000 to
2000 FT
2.0 to 6.0 iNM
10,000 FT
and 6.0 iNM
Model 9900 Fixed 500 FT and
1.0 iNM
Fixed 1000 FT
and 2.0 iNM
Fixed 2000 FT
and 3.0 iNM
5,000 FT and
3.0 iNM
Figure 1-2 Air Traffic Shield Limits
1.4 FACTORY SETTINGS
The Ryan TCAD 9900 Series is delivered with the following settings:
Audio Volume: Mid Range
Mute Duration: 30 seconds
ENRT Shield Size: ±2000 feet, 3.0 iNM
STD Shield Size ±1000 feet, 2.0 iNM
TRML Shield Size: ±500 feet, 1.0 iNM
Altimeter Setting: 29.92 inches
Density Altitude Temperature: +59°F (+15°C)
Altitude Alert: 5,000 feet
Voice Enabled (9900A and 9900B)
1.5 UNITS AND ACCESSORIES SUPPLIED
Ryan TCAD 9900 Series Model 9900 (P/N 71-2000), Model 9900A (P/N 71-2200) and
Model 9900B (P/N 71-2400) consisting of:
A. Ryan TCAD 9900 Series Display Assembly, including:
a. Display Unit:
Model 9900 P/N 70-2100
Model 9900A P/N 70-2300
Model 9900B P/N 70-2500
b. Display Clamp Assembly P/N 28-3110
c. Display Connector kit P/N 61-2003, including
(a) 9 pin ‘D’ Connector - Socket
(b) 9-pin ‘D’ Shell
(c) ‘D’ Connector Jack Screw Kit
(d) ‘D’ Connector Socket Pins
An optional second Display is available.
