Revision 4 - December 17,1998 Ryan TCAD 9900 Series Page 1-5
B. Ryan TCAD 9900 Series Processor Assembly, including:
a. Processor Unit:
P/N 70-2000 (9900), P/N 70-2200 (9900A), P/N 70-2400 (9900B)
b. Mounting Tray P/N 60-2006 with Doubler Plate (P/N 28-2208)
c. Processor Connectors P/N 62-2001
(a) 9-pin ‘D’ Connector jack screws and shell - (jumper installed)
(b) 15-pin ‘D’ Plug Connector, jack screws, pins and shell
(c) 25-pin ‘D’ Socket Connector, jack screws, pins and shell
d. EMI and DME Suppression Kit P/N 62-2003
(a) Two diodes, one resistor and one inductor
C. Transponder Coupler, P/N 70-2040
a. Two Type ‘N’ Plug Connectors, P/N 62-2040
b. Four Mounting Screws, 6-32 x 1-3/8”, Stainless Steel
NOTE: If dual transponders are installed on the aircraft, a second Transponder
Coupler with accessories is required.
D. Literature Pack, P/N 63-2004
a. Installation Manual, 9900 Series
b. Pilot's Operating Handbook (POH), 9900 Series, including the
Multifunction Display (MFD) Interface Supplement to the Pilot's
Operating Handbook
c. Instructions for Continued Airworthiness
d. Information Concerning Instructions for Continued Airworthiness
e. Sample Flight Manual Supplement for TCAD
f. Copy of STC 1763GL
E. Model 9900B:
a. Bearing Antenna Kit P/N 70-2410 consisting of:
(a) Two L-Band antennas, Top (T) and Bottom (B), conforming
to TSO C74c and U.S. Patent 5,552,788. Sensor Systems
P/N S72-1750-31L and S72-1750-32L
(b) Two Doubler Plates, Sensor Systems P/N S72-17500-1
b. Model 9900B Multifunction Display Literature Pack, P/N 63-2003,
including:
(a) Multifunction Display Interface Installation Instructions
(b) Multifunction Display Interface Supplement to the Pilot's
Operating Handbook (included in POH, see D. above)
(c) Sample Flight Manual Supplement for MFD Interface
(d) Copy of STC 00900NY
1.6 LICENSE REQUIREMENTS
The Ryan TCAD is a passive receiver, and does not require an Aircraft Station License.
