PART II: Special Version
LVIF1019A++44M
Cutlery basket could be have 5 positions:
Mode 1 Position one: lift the left basket
up, both left and right baskets
are sideling
Mode 2 Position two: adjust the
leftbasket to lower position,
leftbasket is at and
rightbasket is sideling
Mode 3 Position three: lift the
rightbasket up, both left
andright baskets are at
Mode 4 Position Four: Move the
rightbasket from right to left,
twobasket are overlapping
Mode 5
Position Five: Remove the
rightbasket from the tray,
onlyhas the left basket
101100
