SOUTHERN AVIONICS COMPANY
Model SA100 Dual 4-25Installation and Operation
4.4.2.2 Parts Lists
Outdoor Mount Load Center/Batt Charger 110VAC SLE11001 Assembly
REF. DES. PART NUMBER DESCRIPTION
A1 9P690004 POWER SUPPLY, 120VAC/24VDC, 10A
CB1 9C350020 CKT BREAKER, 2 POLE, 277VAC/65VDC, 15 AMP
CB2 9C350021 CKT BREAKER, 1 POLE, 227VAC/65VDC, 15 AMP
CR1 1D119600 DIODE, 400V 18A
F1 9F830150 FUSE, 15 AMP, 250V, ABC FAST ACTING TYPE
F2 9F830032 FUSE, 3 AMP, 250V, 3AG (AGC) FAST ACTING TYPE
F3 9F830032 FUSE, 3 AMP, 250V, 3AG (AGC) FAST ACTING TYPE
F4 9F830150 FUSE, 15 AMP, 250V, ABC FAST ACTING TYPE
R1 1R4A20A0 RES, .02 OHM, 50W, 1%, WW
S1 9S900029 SWITCH, DPST, ROCKER, HIGH INRUSH, SNAP IN
To Next Page
