26 FP5/GP5 User’s Manual
Chapter 1 - Receiving & Installation
Wiring
460V Class Wire Size
* Wire sizes are based on 75°C copper wire.
Circuit
Model
CIMR-
Terminal Symbol
Terminal
Screw
Wire Size *
Max. Torque
lb-in (N·m)
Wire Type
AWG mm
2
Main
P5U40P4
L1, L2, L3, , ⊕1, ⊕2, B1, B2, T1, T2, T3
M4 14 - 10 2 - 5.5 12.4 (1.4)
Power cable:
600V vinyl
sheathed wire
or equivalent
P5U40P7
L1, L2, L3, , ⊕1, ⊕2, B1, B2, T1, T2, T3
M4
14 - 10 2 - 5.5
12.4 (1.4)
12 - 103.5 - 5.5
P5U41P5
L1, L2, L3, , ⊕1, ⊕2, B1, B2, T1, T2, T3
M4
14 - 10 2 - 5.5
12.4 (1.4)
12 - 103.5 - 5.5
P5U42P2
L1, L2, L3, , ⊕1, ⊕2, B1, B2, T1, T2, T3
M4
14 - 10 2 - 5.5
12.4 (1.4)
12 - 103.5 - 5.5
P5U43P7
L1, L2, L3, , ⊕1, ⊕2, B1, B2, T1, T2, T3
M4
14 - 10 2 - 5.5
12.4 (1.4)
12 - 103.5 - 5.5
P5U45P5
L1, L2, L3, , ⊕1, ⊕2, B1, B2, T1, T2, T3
M4 12 - 103.5 - 5.5 12.4 (1.4)
P5U47P5
L1, L2, L3, , ⊕1, ⊕2, B1, B2, T1, T2, T3
M5 8 - 6 8 - 14 22.1 (2.5)
P5U4011
L1, L2, L3, , ⊕1, ⊕2, B1, B2, T1, T2, T3 M5 8 - 6 8 - 14 22.1 (2.5)
M6 8 - 6 8 - 14 45.1 (5.1)
P5U4015
L1, L2, L3, , ⊕1, ⊕2, B1, B2, T1, T2, T3 M5 8 - 6 8 - 14 22.1 (2.5)
M6 8 - 6 8 - 14 45.1 (5.1)
P5U4018
L1, L2, L3, L11, L21, L31, T1, T2, T3 M6 6 14 45.1 (5.1)
M8 8 - 6 8 - 14 90.3 (10.2)
P5U4022
L1, L2, L3, L11, L21, L31, T1, T2, T3 M6 4 22 45.1 (5.1)
M8 4 22 90.3 (10.2)
P5U4030
L1, L2, L3, L11, L21, L31, T1, T2, T3
M8
4 22
90.3 (10.2)
4 22
P5U4037
L1, L2, L3, L11, L21, L31, T1, T2, T3
M8
3 30
90.3 (10.2)
4 22
P5U4045
L1, L2, L3, L11, L21, L31, T1, T2, T3
M8
1 50
90.3 (10.2)
3 30
P5U4055
L1, L2, L3, L11, L21, L31, T1, T2, T3 M10 4/0 100 203.6 (23.0)
M8 1 50 90.3 (10.2)
P5U4075
L1, L2, L3, L11, L21, L31, T1, T2, T3 M10 1/0 x 2P60 x 2P 203.6 (23.0)
M8 1/0 60 90.3 (10.2)
P5U4110
L1, L2, L3, L11, L21, L31, T1, T2, T3 M10 1/0 x 2P60 x 2P 203.6 (23.0)
M8 1/0 60 90.3 (10.2)
P5U4160
L1, L2, L3, L11, L21, L31, T1, T2, T3 M12 4/0 x 2P100 x 2P349.6 (39.5)
M8 4/0 100 90.3 (10.2)
P5U4185
L1, L2, L3, , ⊕1, ⊕3, T1, T2, T3
M16
650MCM
x 2P
325 x 2P867.4 (98.0)
M8 650MCM 325 90.3 (10.2)
r, s200, s400 M4 20 - 100.5 - 5.5 12.4 (1.4)
P5U4220
L1, L2, L3, , ⊕1, ⊕3, T1, T2, T3
M16
650MCM
x 2P
325 x 2P867.4 (98.0)
M8 650MCM 325 90.3 (10.2)
r, s200, s400 M4 20 - 100.5 - 5.5 12.4 (1.4)
P5U4300
L1, L2, L3, , ⊕1, ⊕3, T1, T2, T3
M16
650MCM
x 2P
325 x 2P867.4 (98.0)
M8 650MCM 325 90.3 (10.2)
r, s200, s400 M4 20 - 100.5 - 5.5 12.4 (1.4)
Control
Common
to all
models
S1, S2, S3, S4, S5, S6, SC
FV, FI, FS, FC
AM, AC, M1, M2, MA, MB, MC
- 20 - 16
Stranded
0.5 - 1.25
Solid
0.5 - 1.25
-
Twisted
shielded wire
with Class 1
wiring
G M3.5 20 - 14 0.5 - 2 8.9 (1.0)
