Motor thermal protection
(Motor OL Sel)
LED Setting LCD Setting Description
0 Disabled Protection disabled
1 STD Motor/8 min General-purpose motor (time
constant 8 min.)
2 STD Motor/5 min General-purpose motor (time
constant 5 min.)
3 INV Motor/8 min Blower-cooled motor (time
constant 8 min.)
4 INV Motor/ 5 min Blower-cooled motor (time
constant 5 min.)
STD
Motor/
8 min
62
n035Stop method selection -
OH1- for inverter
overheat pre-alarm
(OH1 Stop Method)
LED Setting LCD Setting Description
0 Ramp STOP/Decel 1Ramp to stop - Decel 1
(fault)
1 Coast to STOP Coast to stop (fault)
2 Ramp STOP/Decel 2Ramp to stop - Decel 2
(fault)
3 Continue Oper Continue operation
(alarm) at 80% of fre-
quency reference
Continue
Oper
-
n036Multi-function input selec-
tion 1
(Terminal S2 Sel)
LED LCD
Setting Setting Description
0 Reverse RUN (2W) Reverse run (2-wire sequence)
1 FWD/REV Cmd (3W)Fwd / Rev command (3-wire sequence)
2 Ext Fault (NO) External fault (normally open)
3 Ext Fault (NC) External fault (normally closed)
4 Fault Reset Fault reset
5 LOCAL/REMOTE SelLocal / Remote selection
6 COM/INV Sel Serial com/inverter selection (Fref, RUN
command)
7 STOP Cmd/Dec2 NOFast stop using Decel 2 (normally open)
8 STOP Cmd/Dec2 NCFast stop using Decel 2 (normally
closed)
9 Master Fref Sel Master freq. ref. selection (FV-open or
FI-closed)
10 Multi-Step Spd 1 Multi-step speed reference command 1
11 Multi-Step Spd 2 Multi-step speed reference command 2
12 Not Used Not used
13 JOG Command Jog reference (n030)
14 Acc/Dec Switch Accel / Decel time selection
15 Ext Baseblk (NO) External baseblock (normally open)
16 Ext Baseblk (NC) External baseblock (normally closed)
17 SpdSrch (MAXFRQ)Speed search from maximum fre-
quency
18 SpdSrch (SETFRQ)Speed search from set frequency
19 Param Lockout Parameter setting enable / disable
20 PID I Reset PID integral value reset
21 PID Disable PID control enable / disable
22 Timer Start Cmd Timer function
23 OH3 Input External overheat alarm (OH3)
24 Ref Sample Hold Analog reference sample hold com-
mand
25 KEB Cmd (NO) Inertia ridethrough command (normally
open)
26 KEB Cmd (NC) Inertia ridethrough command (normally
closed)
27 Hold Command Accel / Decel hold command
28 PID Polarity Sel Inverse PID enable / disable
Reverse
RUN
(2W)
78
No. Function Name
(LCD Operator Display)
Description Factory
Default
User
Setting
Ref.
Page
Chapter 3 - Programming Features
FP5/GP5 Parameters
