FP5/GP5 User’s Manual 45
n047Frequency reference level
at loss of Fref
(Fref Lvl@F Loss)
Unit: 1%
Setting range: 0~100% of setting Fref
80% 82
n048Terminal FV gain
(Terminal FV Gain)
Unit: 1%
Setting range: 0~200%
100% 59,96
n049Terminal FV bias
(Terminal FV Bias)
Unit: 1%
Setting range: -100~100%
0% 59,96
n050
Terminal FI gain
(Terminal FI Gain)
Unit: 1%
Setting range: 0~200%
100% 59
n051Terminal FI bias
(Terminal FI Bias)
Unit: 1%
Setting range: -100~100%
0% 59
n052Multi-function analog
output AM
(Terminal AM Sel)
LED
Setting LCD Setting Monitor
0 Output Freq Output frequency
1 Output Amps Output current
2 Output kWatts Output power
3 DC Bus Voltage DC bus voltage
Output
Freq
58
n053
Analog monitor gain
(Terminal AM Gain)
Unit: 0.01
Setting range: 0.01~2.00
1.00 58
n054
Carrier frequency
(Carrier Freq Sel)
Unit: 1
Setting range: 1~6 (x2.5kHz), 7~9 (custom pattern)
kVA
dependent
51
n055Momentary power loss
ridethrough method
(PwrL Selection)
LED LCD
Setting Setting Method
0 Not Provided Not provided
1 2 Seconds Max Continuous operation after
power recovery within 2s
2 CPU Power Active Continuous operation after
power recovery within control
logic time (no fault output)
Not
Provided
51
n056Speed search level -
decel time fixed at 2 sec
(SpdSrch Current)
Unit: 1% Setting range: 0~200%
100% = inverter rated current
110% 74
n057Minimum baseblock time
(Min Baseblock t)
Unit: 0.1s
Setting range: 0.5~10.0s
kVA
dependent
71
n058V/f reduction level during
speed search
(SpdSrch V/f)
Unit:1%
Setting range: 0~100%
kVA
dependent
-
n059Power loss ridethrough
time
(PwrL Ridethru t)
Unit: 0.1s
Setting range: 0.0~2.0s
kVA
dependent
-
n060Automatic retry attempts
(Num of Restarts)
Unit: 1 time
Setting range: 0~10
0 51
n061Fault contact selection
during automatic retry
(Restart Sel)
LED
Setting LCD Setting Description
0 Activate Flt Rly Closed during fault retry
1 No Rly Output Open during fault retry
Activate
Flt Rly
-
n062Jump frequency 1
(Jump Freq 1)
Unit: 0.1Hz
Setting range: 0.0~400.0Hz
0.0Hz 60
n063
Jump frequency 2
(Jump Freq 2)
Unit: 0.1Hz
Setting range: 0.0~400.0Hz
0.0Hz 60
n064
Jump frequency
bandwidth
(Jump Bandwidth)
Unit: 0.1Hz
Setting range: 0.0~25.5Hz
1.0Hz 60
No. Function Name
(LCD Operator Display)
Description Factory
Default
User
Setting
Ref.
Page
Chapter 3 - Programming Features
FP5/GP5 Parameters
