FP5/GP5 User’s Manual 9
FP5/GP5
Inverter Model
CIMR-P5U
2018202220302037204520552075
—
Output Characteristics
Motor Output (HP) * 30 40 50 60 75 100125
Capacity (kVA) 30 37 50 61 70 85 110
Rated Output
Current (A) - VT **
80 104 130 160 192 248 312
Rated Output
Current (A) - CT **
64 83 104128154198250
Max. Voltage
3-Phase, 200/208/220/230V
(Proportional to input voltage)
Rated Output Frequency 0.1 to 400 Hz
Overload Capacity - VT ** 120% Rated Output Current / 1 minute
Overload Capacity - CT ** 150% Rated Output Current / 1 minute
Power Supply
Input Current (A) 88 119143176212270344
—
Rated Voltage &
Frequency
3-Phase
220 - 230V, 50/60Hz
Voltage Fluctuation +10%, -15%
Frequency Fluctuation ±5%
CIMR-P5U 401840224030403740454055407541104160418542204300
Output Characteristics
Motor Output (HP) * 30 40 50 60 75 100150200250300400500
Capacity (kVA) 31 40 50 61 73 98 130170230260340460
Rated Output
Current (A) - VT **
41 52 65 80 96 128 180 240 302 380 506 675
Rated Output
Current (A) - CT **
32 42 52 64 77 102144182242304404540
Max. Voltage
#
3-Phase, 380/400/415/440/460V
(Proportional to input voltage)
Rated Output Frequency 0.1 to 400 Hz
Overload Capacity - VT ** 120% Rated Current / 1 minute
Overload Capacity - CT ** 150% Rated Current / 1 minute
Power Supply
Input Current (A) 46 58 72 88 106141198264330456608810
Rated Voltage &
Frequency
#
3-Phase
380 -440 - 460V, 50/60Hz
Voltage Fluctuation +10%, -15%
Frequency Fluctuation ±5%
Chapter 1 - Receiving & Installation
Specifications
* HP ratings based on standard NEMA 4-pole motor data.
#
For 380V operation, the motor rated current must be less than or equal to the inverter
rated current.
** VT: Variable Torque rating (n116=1), CT: Constant Torque rating (n116=0)
Note: Shaded areas indicate factory settings.
