Saftronics HPVFE User Manual

70
Motor and/or drive will not accelerate to commanded speed.
Cause(s)
Indication
Corrective Action
Acceleration time is excessive.
None
Reprogram P109 [Accel Time 1] or A401
[Accel Time 2].
Excess load or short acceleration times
force the drive into current limit, slowing or
stopping acceleration.
None
Compare d003 [Output Current] with A441
[Current Limit].
Remove excess load or reprogram P109
[Accel Time 1] or A401 [Accel Time 2].
Check for improper A453 [Boost Select]
setting.
Speed command source or value is not as
expected.
None
Verify d002 [Commanded Freq].
Check d012 [Control Source] for the
proper Speed Command.
Programming is preventing the drive output
from exceeding limiting values.
None
Check P105 [Maximum Freq] to insure
that speed is not limited by programming.
Motor operation is unstable.
Cause(s)
Indication
Corrective Action
Motor data was incorrectly entered.
None
1.Correctly enter motor nameplate data
into P101, P102 and P103.
2.Enable A436 [Compensation].
3.Use A453 [Boost Select] to reduce boost
level.
Drive will not reverse motor direction.
Cause(s)
Indication
Corrective Action
Digital input is not selected for reversing
control.
None
Check [Digital Inx Sel] (See page 3-13).
Choose correct input and program for
reversing mode.
Digital input is incorrectly wired.
None
Check input wiring. (See page 1-14)
Motor wiring is improperly phased for
reverse.
None
Switch two motor leads.
Reverse is disabled.
None
Check A434 [Reverse Disable].
Drive does not power up.
Cause(s)
Indication
Corrective Action
No input power to drive.
None
Check the power circuit.
Check the supply voltage.
Check all fuses and disconnects.
Jumper between I/O Terminals P2 and P1
not installed and/or DC Bus Inductor not
connected.
None
Install jumper or connect DC Bus Inductor.
