Saftronics HPVFE User Manual

72
Specifications
Drive Ratings
Catalog Numbe r
Frame
S ize
W × H× D
Input Vo l tage
kW
HP
Output
Current(A)
240V 50/60Hz
1- phase
0.2
0.25
1 .6
HPVFE02S0D2
A
72×185.5×143.5
0.4
0.5
2.5
HPVFE02S0D4
0.75
1
4.2
HPVFE02S0D75
1.5
2
8
HPVFE02S1D5
B
100×1 7 4×1 45
2.2
3
11
HPVFE02S2D2
240V 50/60Hz
1- phase ,with
filt er (1)
0.2
0.25
1 .6
HPVFE02S0D201
A
72×185.5×143.5
0.4
0.5
2.5
HPVFE02S0D401
0.75
1
4.2
HPVFE02S0D7501
1.5
2
8
HPVFE02S1D501
B
100×1 7 4×1 45
2.2
3
11
HPVFE02S2D201
240V 50/60Hz
3- phase
0.2
0.25
1 .6
HPVFE02T0D2
A
72×185.5×143.5
0.4
0.5
2.5
HPVFE02T0D4
0.75
1
4.2
HPVFE02T0D75
1.5
2
8
HPVFE02T1D5
2.2
3
12
HPVFE02T2D2
B
100×1 7 4×1 45
3.7
5
17.5
HPVFE02T3D7
5.5
7.5
25
HPVFE02T5D5
C
130×25 3×287
7.5
10
33
HPVFE02T7D5
480V 50/60Hz
3- phase
0.4
0.5
1.5
HPVFE04T0D4
A
72×185.5×143.5
0.75
1
2.5
HPVFE04T0D75
1.5
2
4.2
HPVFE04T1D5
2.2
3
6
HPVFE04T2D2
B
100×1 7 4×1 45
3.7
5
8.7
HPVFE04T3D7
5.5
7.5
13
HPVFE04T5D5
C
130×25 3×287
7.5
10
18
HPVFE04T7D5
11
15
24
HPVFE04T11
480V 50/60Hz
3- phase
with f ilt er (1)
0.4
0.5
1.5
HPVFE04T0D401
A
72×185.5×143.5
0.75
1.0
2.5
HPVFE04T0D7501
1.5
2.0
4.2
HPVFE04T1D501
2.2
3.0
6.0
HPVFE04T2D201
B
100×1 7 4×1 45
3.7
5.0
8.7
HPVFE04T3D701
5.5
7.5
13.0
HPVFE04T5D501
C
130×25 3×287
7.5
10.0
18.0
HPVFE04T7D501
11.0
15.0
24.0
HPVFE04T1101
Note ： 5.5kW and above, an internal brake IGBT is supplied.
