Input/Output Ratings
Output Frequency:
0-400 Hz (Programmable)
Efficiency:
97.5% (Typical)
Digital Control Inputs (Input Current = 6mA)
SRC (Source) Mode:
18-24V = ON
0-6V = OFF
SNK (Sink) Mode:
0-6V = ON
18-24V = OFF
4-20mA Analog:
250 ohm input impedance
0-10V DC Analog:
100k ohm input impedance
External Pot:
1-10k ohms, 2 Watt minimum
Control Output (Programmable Output, form C relay)
Resistive Rating:
3.0A at 30V DC, 125V AC and 240V
ACInductive
Rating:
0.5A at 30V DC, 125V AC, and 240V AC
Recommended Fuses and Circuit Breakers
Fuse:
UL Class J, RK1, T or Type BS88; 600V (550V) or equivalent.
Circuit Breakers:
HMCP or Bulletin 140M or equivalent.
Protective Features
Motor Protection:
I2t overload protection - 150% for 60 Secs, 200% for 3 Secs (Provides Class 10 protection)
Overcurrent:
200% hardware limit, 300% instantaneous fault
Over
Voltage:100-120V
AC Input – Trip occurs at 405V DC bus voltage (equivalent to 150V AC incoming line)
200-240V AC Input – Trip occurs at 405V DC bus voltage (equivalent to 290V AC incoming line)
380-460V AC Input – Trip occurs at 810V DC bus voltage (equivalent to 575V AC incoming line)
Under
Voltage:100-120V
AC Input – Trip occurs at 210V DC bus voltage (equivalent to 75V AC incoming line)
200-240V AC Input – Trip occurs at 210V DC bus voltage (equivalent to 150V AC incoming line)
380-480V AC Input – Trip occurs at 390V DC bus voltage (equivalent to 275V AC incoming line)
Control Ride Through:
Minimum ride through is 0.5 Secs - typical value 2 Secs
Faultless Power Ride Through:
100 milliseconds
Dynamic Braking
Internal brake IGBT included with power ratings 5.5 kW (7.5 HP) and 7.5 kW (10.0 HP) for 240V, 3-phase drives and 5.5 kW (7.5 HP), 7.5 kW (10.0 HP) and 11.0 kW (15.0
HP) for 480V, 3-phase drives. See Appendix B for ordering information.
