Saftronics HPVFE User Manual

74
Category
Specification
Environment
Altitude:
1000 m (3300 ft) max. without derating
Maximum Surrounding Air
Temperature without derating:
IP20:
IP20 zero stacking:
–10 to 50° C (14 to 122° F)
–10 to 40° C (14 to 104° F)
Cooling Method
Convection:
Fan:
120V, 1-Phase, 0.75 kW (1 HP) and below
240V, 1-Phase, 0.4 kW (0.5 HP) and below
240V, 3-Phase, 0.75 kW (1 HP) and below
480V, 3-Phase, 0.75 kW (1 HP) and below
All other drive ratings.
Storage Temperature:
–40 to 85 degrees C (–40 to 185 degrees F)
Atmosphere:
Important: Drive must not be installed in an area
where the ambient atmosphere contains volatile or
corrosive gas, vapors or dust. If the drive is not going to
be installed for a period of time, it must be stored in an
area where it will not be exposed to a corrosive
atmosphere.
Relative Humidity:
0 to 95% non-condensing
Shock (operating):
15G peak for 11ms duration (±1.0ms)
Vibration (operating):
1G peak, 5 to 2000 Hz
Control
Carrier Frequency
2-10 kHz. Drive rating based on 4 kHz.
Frequency Accuracy
Digital Input:
Analog Input:
Within ±0.05% of set output frequency.
Within 0.5% of maximum output frequency.
Speed Regulation - Open Loop with Slip
Compensation:
±2% of base speed across a 40:1 speed range.
Stop Modes:
Multiple programmable stop modes including - Ramp,
Coast, DC-Brake, Ramp-to-Hold and
S Curve.
Acceleration/Deceleration:
Two independently programmable acceleration and
deceleration times. Each time may be programmed from 0
- 600 seconds in 0.1 second increments.
Intermittent Overload:
150% Overload capability for up to 1 minute
200% Overload capability for up to 3 seconds
Electronic Motor Overload Protection
Class 10 protection with speed sensitive response and
power-down overload retention function.
Electrical
Voltage Tolerance:
200-240V ±10%
380-480V ±10%
460-600V ±10%
Frequency Tolerance:
48-63 Hz
Input Phases:
Three-phase input provides full rating. Single-phase operation
provides 35% rated current.
Displacement Power Factor:
0.98 across entire speed range
Maximum Short Circuit Rating:
100,000 Amps Symmetrical
Actual Short Circuit Rating:
Determined by AIC Rating of installed fuse/circuit breaker
Transistor Type:
Isolated Gate Bipolar (IGBT)
