Saftronics HPVFE User Manual

Sailer Manual HPVFE Sailer Manual HPVFE
7
Chapter 1 Installation/Wiring
This chapter provides information on mounting and wiring the HPVFE Drive.
For information on…
See page
For information on…
See page
Opening the Cover
1-1
Fuses and Circuit Breakers
1-7
Mounting Considerations
1-2
Power Wiring
1-9
AC Supply Source Considerations
1-3
I/O Wiring Recommendations
1-13
General Grounding Requirements
1-5
EMC Instructions
1-21
Most start-up difficulties are the result of incorrect wiring. Every precaution must be taken to assure that the wiring
is done as instructed. All items must be read and understood before the actual installation begins.
1. Press and hold in the tabs on each side of the cover.
2. Pull the cover out and up to release.
ATTENTION: The following information is merely a guide for proper installation. Rockwell
Automation, Inc. cannot assume responsibility for the compliance or the noncompliance to any code,
national, local or otherwise for the proper installation of this drive or associated equipment. A hazard
Of personal injury and/or equipment damage exists if codes are ignored during installation.
Opening the Cover
1. Press and hold in the tabs on each side of the cover.
2. Pull the cover out and up to release

Saftronics HPVFE Specifications

General

Brand	Saftronics
Model	HPVFE
Category	DC Drives
Language	English
