t201 [Digital In1 Sel] Related Parameter(s): d012, d014, P108, P109, P110,
(I/O Terminal 5) t211-t214, A401, A402, A404, A405, A410-A413
t202 [Digital In2 Sel] Stop drive before changing this parameter.
(I/O Terminal 6)
Selects the function for the digital inputs. Refer to the flowchart on page 1-19 for more information on speed reference control priority.
Options 0 “Not Used” Terminal has no function but can be read over network communications via d014
[Dig In Status]
1 “Acc 2 & Dec 2”
When active, A401 [Accel Time 2] and A402 [Decel Time 2] are used for all ramp
rates except Jog.
Can only be tied to one input.
Refer to the flowchart on page 1-20 for more information on Accel/Decel selection.
2 “Jog”
When input is present, drive accelerates according to the value set in A405 [Jog
Accel/Decel] and ramps to the value set in A404 [Jog Frequency].
When input is removed, drive ramps to a stop according to the value set in A405
[Jog Accel/Decel].
A valid “Start” command will override this input.
3 “Aux Fault” When enabled, an F2 Auxiliary Input fault will occur when the input is removed.
4 “Preset Freq” (Default) Refer to A410 - A413 [Preset Freq x].
Important: Digital Inputs have priority for frequency control when programmed
as a Preset Speed and are active. Refer to the flowchart on 1-19 for more
information on speed reference control priority.
5 “Local” When active, sets integral keypad as start source and potentiometer on the integral
keypad as speed source.
6 “Comm Port”
When active, sets communications device as default start/speed command
source.
Can only be tied to one input.
7 “Clear Fault”
When active, clears an active fault.
8 “RampStop,CF” Causes drive to immediately ramp to a stop regardless of how P107 [Stop Mode] is
set.
9 “CoastStop,CF” Causes drive to immediately coast to a stop regardless of how P107 [Stop Mode]
is set.
10 “DCInjStop,CF” Causes drive to immediately begin a DC Injection stop regardless of how P107
[Stop Mode] is set.
11 “Jog Forward” Drive accelerates to A404 [Jog Frequency] according to A405 [Jog Accel/Decel]
and ramps to stop when input becomes inactive. A valid start will override this
command.
12 “Jog Reverse” Drive accelerates to A404 [Jog Frequency] according to A405 [Jog Accel/Decel]
and ramps to stop when input becomes inactive. A valid start will override this
command.
