Sage Digital ENDEC Quick Start Rev 2.0
Item Name Description
Gnd Grounds for the various unbalanced audio inputs.
Mon n In (1 – 6) Unbalanced 600 ohm inputs for alert audio sources, .75Vrms typical, do not
exceed 2Vrms.
Enc In A high-level audio input for locally originated audio.
D in 1 (previously
called Manual
Override)
A digital input that the ENDEC reads as open (floating) or closed (ground).
Used for various options such as alert hold off or sending a Weekly Test.
Line Out Unbalanced 600 ohm output for alert audio or monitoring the inputs.
Spkr Out Separate unbalanced 600 ohm output, can be used for an external speaker or to
feed the internal speaker through Spkr In.
Spkr In The internal speaker, usually fed from Spkr Out. The path is made available
on the back panel to allow routing through a console for muting.
2 XLR In and Out Stereo input and output connectors for station audio. The ENDEC normally
passes this through on a hard relay (no audio processing). During an alert, the
output is switched to the ENDEC’s internal sources.
3 Serial Ports
Five serial ports, COM2 through COM5, that you can assign to any device.
See section 14.1 Serial Port Pin Out on page 21.
4 Power
Power input and power switch. Use the power cube supplied with the
ENDEC, 19v, 2A. Do not use the power cube from the original “gray box”
ENDEC.
5 Digital Audio AES/EBU digital input and output.
6
LAN 10/100 LAN connection.
USB 1 and 2 USB connection, used for flash drive, printer, etc.
