Appendix A: Technical specifications
56 Transceiver unit SAILOR 6222 VHF DSC
Current consumption at
12 VDC without any
accessories connected
RX: 0.5 A
TX: 5 A
Current consumption at
12 VDC with all accessories
connected
RX: 0.7 A
TX: 7 A
Frequency range TX: 156,000 MHz — 157,425 MHz,
RX: 156,000 MHz — 163.425 MHz
Item Specification
Channel spacing 12.5 kHz and 25 kHz, all international maritime
channels
Number of P channels The radio may be programmed with up to 100
private channels that can be managed in all
channel modes.
Modulation
25 kHz
12.5 kHz
16K0G3E, 16KOG2B (DSC)
8K05G3E
Antenna 50 Ohm antenna, 50 Ohm female SO239 for
PL259 plug
2-antenna operation for VHF and DSC
communication
Water ingress IPx8 and IPx6 all over. For flush-mount
installations a sealing gasket is included in the
delivery.
Item Specification
