Appendix A: Technical specifications
Transceiver unit SAILOR 6222 VHF DSC 57
AAAA
Technical specifications
Transmitter
Transmit power Hi/Lo: 25 W and 1 W
RF output power High: 25 W +0 dB / - 1.5 dB
Low: 1 W +0 dB / - 1.5 dB
RF output power, Canada High: 21 W ±0.75 dB
Low: 0.8 W ±0.75 dB
Frequency error Below 500 Hz
Adjacent channel power Below 75 dB
Conducted spurious emission Below 0.25 W
Distortion Below 3%
S/N ratio Better than 46 dB
Receiver
Sensitivity < -119 dBm typically @ 20 dB SINAD CCITT
weighted
LF power Built-in loudspeaker: 6 W (at 5 kHz dev./1 kHz
tone)
External loudspeaker: 6 W / 8 Ohm
Distortion Below 5%
Item Specification
