8000m Series
- 31 -
Function
Code
Function Descriptions
Minimum
Unit
Factory
Setting
Modifica-
tion Type
F0.03
Settings of master
frequency source X
3: Reserved
4: Reserved
5: Reserved
6: Multi-function digital input
terminals
7: PLC
8: PID
9: Communication interface
1 ●
F0.04
Settings of
auxiliary
frequency source Y
0: AVI terminal
1: Reserved
2: Reserved
1 ●
F0.05
Setting range of
auxiliary
frequency source Y
when it is
superposed
0 : Relative to the maxi.
Frequency
1: Relative to master frequency
setting source X
0 ●
F0.06 Reserved
F0.07
Frequency
reference selection
0:X
1: Y
2: X and Y
3: Max. value of (X, Y)
0 ○
F0.08
Keypad setting
frequency
0.00Hz~ F0.10 0.01Hz 50.00 Hz ○
F0.09
Running direction
selection
0: Forward
1: Reverse
2: Reverse running prohibited
0 ●
F0.10
Max. output
frequency
10.00~600.00Hz 0.01Hz 50.00Hz ●
F0.11
Upper limit
frequency source
selection
0: Keypad (F0.12)
1: AVI terminal
2: Reserved
3: Multi-function digital input
terminals
4: Communication interface
0 ○
